Allowable Load: 3 tons
Control Method:Dual-channel control(via mobile APP/remote controller), with real-time transmission of high-definition images
Turning Mode: 360° in-place rotation
Slope Adaptability: ≤13°
Power Battery: Ternary lithium battery (48V/50A)
Load-Carrying Performance: Can travel 3.6 kilometers with a load of 3,000 kg
Lighting Method: LED light strip/lighting system
Lifting Power:Dual-motor synchronous lifting
Lifting Method: Scissor-type lifting
Control System: Android system mobile APP (Wi-Fi connection)
Input Voltage: Manual AC220V three-pin interface
Superior Protection: IP55 waterproof/1000° C high-temperature resistance, fearless of extreme environments

GET A QUOTE

Description

1、Basic Parameters

Item	Parameter
Overall Dimensions（mm）	Length 1420-1900 / Width 1100-1985 / Height 140-430
Overall Mass（kg）	≤210
Minimum Ground Clearance（mm）	≤25
Three-Speed（m/s）	Low speed 0.09 / Medium speed 0.22 / High speed 0.62
Obstacle Surmounting Height（mm）	≤20
Remote Control/Video Distance（m）	≥100
Total Machine Traction（N）	≥1000
Lighting Brightness（LM）	≥100
Continuous Operating Time（h）	≥4
Charging Method	Manual charging
Waterproof Grade	IP55

Item	Parameter
Carbon Fiber Fire-Resistant Panel	1000° C High-Temperature Resistant + Flame-Retardant Material
Multi-Layer Protective Structure	Sprayed Imported Fire-Retardant Paint + Vacuum Porous Silicone Insulation Layer
High-Temperature Resistant Wire Harness	Level 4 Fire-Retardant Coating, Eliminating Short-Circuit Risks
