| Parameter | Specification |
|---|---|
| Product Series | Point-to-Point Video and Data Transmission Series |
| Application Scenarios | UAV/Car/Ship, Robot, etc. |
| Frequency Range | L-band: 1.4GHz (Others Customizable) |
| RF Channels | 2Tx & 2Rx |
| Output Power | 2 * 3W |
| Operating Voltage | DC +9V~+30V, Typical +24V |
| Maximum Bitrate | > 90Mbps |
| RF Bandwidth | 4/8/10/14/20MHz Optional |
| Transmission Delay (Small Bitrate) | <5ms |
| Transmission Delay (Large Bitrate) | <30ms |
| Product Power Consumption (Air Unit) | <45W (Full-time Transmission) |
| Product Power Consumption (Ground Unit) | <15W |
| Encryption Standard | AES 256bit; Physical Layer Encryption |
| Communication Interfaces | 1IP 2RS232 2*RS422 |
| Product Size | 150mm86mm26mm |
| Product Weight | ≤ 450g |
| Operating Temperature | -40°C ~ +55°C |
| Modulation Mode | QPSK/16QAM/64QAM |
| Air-to-Ground Distance | 100km (Line of Sight) |
| Ground-to-Ground Distance | 4-5km (Line of Sight) |
