| Category | Specifications |
|---|---|
| Product Specs | Default Target Recognition Types: Human, Vehicle Target Recognition Range: Vehicle 1200m Humans 500m Pixel for Tracking: 16*16 Pixels Maximum Tracking Speed for Moving Target: 60km/h Smart Lock on Tracking: Supports crosshair fuzzy locking with close-range target adsorption Trajectory Prediction and Memory Tracking: Supports dual-mechanism tracking with trajectory prediction and feature memory Maximum Number of Supported Recognizable Targets: 50 targets Picture-in-Picture(PIP) Support: Supported |
| AI Module | Main Control Computing Power(TOPS): 6 Control Protocol: CRSF Supported Firmware: BeetFlight APM/Pix4i(development) Input Voltage(V): 9-16 Size(WHD mm): 40x40x25.7 Mounting Hole Position(mm): 2020/25.525.5 |
| Visible-Light Camera | Sensor Size (Inch): 1/2.6 inch (Visible Light 1, Visible Light 2) Focal Length (mm): 3.9, 12 FOV: 72°(W)47°(V), 26°(W)15°(V) Low Light Performance: 9650 mlux/urs (both lenses) Video Input Format: 19201080@60hz (both lenses) Camera Dimensions (LWH mm): 40.825*26 (both lenses) |
| Thermal Imaging Camera | Pixel Pitch: 12um Focal Length: 13mm FOV: 20.2°(W)15.2°(V) Spectral Response: 8~14um (LWIR) Video Input Format: 384288@25hz Camera Dimensions (LWH mm): 262926.3 Interface: USB |
