| Index | Parameter | Index | Parameter |
|---|---|---|---|
| Dimension Reference | 430434175 | Platform Size | 325*256 |
| Chassis Self-weight | ≤12KG | Running Speed | 3.4KM/H |
| Main Body Material | Aluminum Alloy | Surface Protection | Matte Black |
| Ground Clearance | 50MM | Protection Grade | IP54 |
| Steering Mode | In-place Rotation | Maximum Load Capacity | ≤18KG |
| Wheelbase | 255mm | Maximum Span | ≥30mm |
| Maximum Vertical Obstacle Crossing Height | ≥80mm | Maximum Climbing Gradient | ≥20° |
| Tire Diameter | 175mm | Motor | 250W Brushless DC |
| Rated Torque | 3NM | No-load Speed | 482RPM |
