| Parameter Name | Parameter Value |
|---|---|
| Operating Frequency | 76 - 79GHz |
| Antenna Configuration | 4T4R |
| Radar Modulation | FMCW |
| Input Voltage | +9.0V ~ +16.0V DC, Typical 12.0V DC |
| Total Power Consumption | <2.4W / 200mA @12V DC |
| Data Refresh Rate | 50ms |
| Point Cloud Count | 256 points |
| Max Trackable Targets | 64 targets |
| Functional Safety | ASIL B (ISO 26262) |
| Communication Interface | 2 x CAN FD |
| EIRP | ≤30dBm |
| Calibration Range | ±6° |
| Detection Range | 0.2m ~ 120m |
| Range Accuracy | ±0.1m |
| Range Resolution | 0.22m |
| Speed Range | -85m/s ~ +85m/s |
| Speed Accuracy | ±0.08m/s |
| Speed Resolution | 0.1m/s |
| Azimuth Range | ≥±75° (150° total FOV) |
| Azimuth Accuracy | ±0.3° |
| Azimuth Resolution | 4° |
| Elevation Range | ±12° (24° total FOV) |
| Dimensions (excl. connectors) | 89.9mm × 82mm × 17.75mm |
| Weight | 70g |
| Waterproof Rating | IP6K7 & IP6K9K |
| Target Type | Stationary & moving targets (vehicles, pedestrians, obstacles) |
